Close-up on the "blue varnish" version
This specific colour is particularly light since it's made up only of a coloured varnish.
It does, nonetheless, have the same durability properties as a traditional paint (resistance to blows, stone chips, etc.).
This painting technique highlights the carbon fibres of the frame. So it's completely normal to see the fibres, especially when the frame is exposed to daylight - it is not a crack or a chip.
Weight
S: 10.4 kg
M: 10.6 kg
L: 10.7 kg
XL: 10.9 kg
Weight without pedals but with inner tubes, in its basic version (Sram GX Eagle mechanical groupset and Mavic Crossmax aluminium wheels)
Frame
Full carbon with high modulus fibres
1030 g in size M (gross and without derailleur hanger)
31.6 mm seat post
Compatible with dropper posts (internal routing)
Thru axle
BOOST format
PressFit 92 bottom bracket
Compatible with 2 bottle cages
Sram UDH derailleur hanger
Integrated top tube protection (Effetto Mariposa)
Embossed to make it easier to fit your emergency inner tube
Frame warranty: 5 years
Frame paint warranty: 2 years
Drivetrain
2 derailleur/shifter configurations to choose from:
Option 1
SRAM GX Eagle 12-speed rear derailleur and SRAM GX Eagle shifter
Option 2 (white colour only)
SRAM GX AXS rear derailleur and SRAM GX AXS shifter
Truvativ Stylo 6K Aluminium crankset (170 mm for S and M and 175 mm for L and XL)
32-tooth chainring (compatible with 32, 34 and 36 teeth)
SRAM PG1275 10-52 cassette (520%)
SRAM PF 92 bottom bracket
Suspension
RockShox Reba RL 100 mm
32 mm stanchions
Solo Air cartridge
Post mount brakes
Thru axle
BOOST format
Combolock II handlebar lockout (2 positions: open and closed)
Weight: 1650 g
Wheels
2 wheel configurations to choose from:
Option 1:
Mavic Crossmax Tubeless Ready
1760 g
Inner rim width: 25 mm
24 flat spokes
6-bolt rotors
XD freehub
Sealed cartridge bearings
Option 2 (only for the white colour)
Reynolds TR309/289 XC 29
1665 g
Carbon fibre, hookless, Tubeless Ready rims
Inner width: 30 mm / 28 mm
Freehub: Reynolds TR MTN
Spokes (front/rear): 28 / 28
Centerlock disc mount
Lifetime warranty (subject to registration)
Brakes
Sram Level T
Sram Centerline 180 mm front and 160 mm rear rotors
6-bolt rotors
Riding position
Rockrider aluminium stem
-20° angle
60 mm in size S
70 mm in size M
80 mm in size L
90 mm in size XL
Rockrider aluminium flat handlebar
720 mm wide
6.5° angle
256 g
Grips: Rockrider 900 Lock On
Saddle and seat post
Saddle Fizik Argo Vento
230 g
31.6 mm carbon
Length: 350 mm (size S and M) / 400 mm (size L and XL)
255 g
Tyre
Front tyre
Vittoria Barzo 29x2.25
tubeless ready
tan wall 120 TPI
Rear tyre
Vittoria Mezcal reinforced 29 x 2.25
tubeless ready
tan wall 120 TPI
Pedals
Rockrider 520 Grip resin flat pedals
Accessories included
Your mountain bike comes with a bell, lighting, wheel reflectors, and pedals.
CARE TIPS
Your bike's equipment (drivetrain, brakes, etc.) will move around during the first few months of use. Please contact your nearest store's workshop to have your bike correctly adjusted.
